SBE-3503 – 嵌入式3.5吋主機板

SBE-3503 – 嵌入式3.5吋主機板

Industrial 3.5” Embedded SBC with Rock chip ARM Cortex A17 RK3288W, HDMI/LVDS/eDP, USB 2.0, Bluetooth and WIFI

  • Embedded 3.5″ Board
  • Onboard Intel® Atom™ processor E3845
  • Dual Gigabit Ethernet supported
  • (1) SATA-300
  • Watchdog & Hardware Monitor function
  • HDMI/VGA/LVDS multiple display outputs


SBE-3503 – 嵌入式3.5吋主機板

CPU Onboard Intel® Atom™ processor E3845 @1.91GHz (fanless)
Chipset SoC Integrated
System Memory (2) 204-pin SO-DIMM DDR3L-1066/1333 up to 8 GB
Integrated Intel® HD Graphics
(1) HDMI, (1) VGA
(1) LVDS 24 bit dual channel
Ethernet (2) 10/100/1000Mbps with Intel® i211AT

Supports Wake-on-LAN, PXE Boot ROM

USB (4) USB 2.0 and (1) USB 3.0 ports
SATA (1) Serial ATA interface with 300 MB/s transfer rate
Audio Built-in HD Audio Codec with Realtek ALC662
Serial Port (1) RS-232/422/485 with +5V/+12V powered

(1) RS-232

SBE-3503A2GNL 3.5” Embedded SBC with Intel® Atom™ processor E3845 1.91GHz and VGA/LVDS/HDMI, 2 GbE LAN and Audio
