RCK-606/608 – 6U Rackmount Chassis

RCK-606/608 – 6U Rackmount Chassis

6U Rackmount chassis for ATX motherboard or backplane, with up to (4) 5.25" and (6) 3.5" Drive Bays, (3) 120mm Fans. Supports PS/2 PSU and Dual PS/2 Type Redundant Power Supplies

  • 6U 19″ Rackmount Standard Chassis
  • Heavy duty Steel, Black/Dark Grey
  • Supports ATX Motherboard
  • Supports 14/19/20-slot backplane or ATX motherboard
  • Modularized function panel for single, dual or quad systems
  • Modularized card cage for easy installation and maintenance
  • (3) 120mm ball-bearing cooling fans with replaceable air filter
  • Supports single or Dual PS/2 Type Redundant PSU
rck-606-608

Description

RCK-606/608 – 6U Rackmount Chassis

Board Support 14/19/20-slot backplane or ATX Motherboard
Expansion Slots Depends on backplane or motherboard
Drive Bays RCK-606: (4) 5.25” & (2) 3.5”
RCK-608: (2) 5.25” & (6) 3.5”
Front Panel Resets and Keyboard Locks for Single, Dual, and Quad Systems
Modularized panel with HDD Active LED and Power ON/OFF LED
Power Supply Supports single PS/2, Mini Redundant, Dual PS/2 redundant or any other power supplies based on OEM project
Cooling (3) 12cm ball bearing fans with ventilations on top and on the sides of the chassis
Dimensions 482 (W) x 495.3 (D) x 266 (H) mm; 19 (W) x 19.5 (D) x 10.5 (H) inches
Gross Weight 22kg/48.5lbs
