RCK-206ME – 2U Rackmount Chassis

RCK-206ME – 2U Rackmount Chassis

2U Rackmount chassis for extended ATX motherboard with 6 drive bays, 2U redundant power supply, 10 Front LED indicators and built-in System environmental monitor board

  • 2U 19″ Rackmount Standard Chassis
  • (10) Front LEDs for monitoring power supply, HDD activity and fans status
  • Supports E-ATX (12″ x13″) & ATX motherboard
  • (2) 3.5″ and (4) 5.25″ External Drive Bays
  • Built-in System environmental monitor board & (3) 80mm Ball-bearing Fans
rck-206me

Description

RCK-206ME – 2U Rackmount Chassis

Board Support E-ATX, ATX and micro-ATX Motherboard
Expansion Slots (3) 32-bit PCI slot through riser card
Or (2) 32-bit PCI slot + (1) PCIe x16 slot
Drive Bays (2) 3.5″ and (4) 5.25 external drive bays
Front Panel (2) USB 2.0 Ports on front panel
On/Off Switch and Reset Switch, Power ON/OFF LED, (6) HDD Active LED, (1) Fan Failure LED, (2)Temperature Sensor LED
Power Supply 300W ATX power supply or 400W Hot Swap Redundant power supply
Cooling Built-in (2) Temperature and (8) Fan Detect Board for system environmental monitoring
Optional 60mm Ball-bearing Fans
Dimensions 427 (W) x 660 (D) x 88.2 (H) mm; 16.8 (W) x 26.0 (D) x 3.5 (H) inches
Gross Weight 14kg



RCK-206ME-PCI303-300W RCK-206ME with 2U 300W ATX power supply & PCI riser card
RCK-206ME-PCIE303-300W RCK-206ME with 2U 300W ATX power supply & PCIE-303 riser card
RCK-206ME-PCI303-400WR RCK-206ME with 2U 400W ATX Hot Swap Redundant power supply with Active PFC function
PCIE-303 Riser card with (2) 32-bit PCI slot + (1) PCIe x16 slot
MT- SR02 Optional Slide Rails
