RCK-309MA – 3U Rackmount Chassis
3U Rackmount chassis for ATX motherboard, (6) 5.25" external, (3) 3.5" external Drive Bays, ,(2) 60mm Fans.300W ATX power supply
- 3U 19″ Rackmount Standard Chassis
- 10 Front LEDs for monitoring power supply, HDD activity and fans status
- (3) 3.5″ and (6) 5.25 external drive bays
- (4) 5.25″ external, (2) 3.5″ external, and (2) 3.5″ internal Drive Bays
- Supports ATX Motherboard
- Built-in Temperature board with (8) fans sensor detection for system environment monitoring
- (2) 60cm ball bearing fans
Categories: 3U Rackmount Chassis, Industrial Chassis
Description
RCK-309MA – 3U Rackmount Chassis
Board Support | ATX Motherboard |
---|---|
Expansion Slots | Depends on motherboard, up to (6) expansion slots |
Drive Bays | (3) 3.5″ and (6) 5.25″ external drive bays |
Front Panel | (2) USB 2.0 Ports on front panel Power ON/OFF LED, (6) HDD Active LED, (1) Fan Failure LED, (2) Temperature Sensor LED |
Power Supply | Supports 2U type power supply |
Cooling | Built-in Temperature board with (8) fans sensor detection for system environment monitoring |
Dimensions | 482.6 (W) x 528.0 (D) x133 (H) mm; 19 (W) x 20.78 (D) x 4.24 (H) inches |
Net/Gross Weight | 11/13.8kg |
