RMS-405M2-AI – Rackmount Systems
Industrial server system with Intel Intel® Xeon® Silver 4310 Processor, DDR4 LRDIMM (3DS), RDIMM (3DS), up to 5 HDD mobile racks, NVIDIA L4 Tensor Core GPU, 850W power supply
- Supports Intel® Xeon® Scalable processor
- Dual 10Gigabit Ethernet controllers
- Up to (5) SATA-600 with RAID 0, 1, 5 ,10
- IPMI with Virtual Console
- M.2 key M 2280/22110 with PCIe x4 signal
Description
RMS-405M2-AI – Rackmount System
| Motherboard | Supermicro X12SPO-NTF |
|---|---|
| CPU | Intel® Xeon® Silver 4310 Processor |
| Chipset | Intel® C621A |
| System Memory | 8 DIMM slots Up to 2TB Intel® Optane™ Persistent Memory 200 Series Up to 2TB 3DS ECC LRDIMM, DDR4-3200MT/s; Up to 2TB 3DS ECC RDIMM, DDR4-3200MT/s |
| Expansion Slots | (1) PCIe 4.0 x16 with NVIDIA L4 Tensor Core GPU |
| Storage | (3) or (5) HDD mobile rack supports SATA-600 with RAID 0, 1, 5 ,10 (2) M.2 key M 2280/22110 with PCIe x4 signal |
| Front Panal | Power ON/OFF, System Reset, and (2) USB ports |
| Rear Panel | (1) LAN (IPMI), (2) 10GB LAN, (2) USB 3.2 Gen.1, (2) USB 2.0, (1) VGA and (1) COM |
| Cooling | One 12cm Low-Noise Cooling Fan with air ventilation. and High performace CPU cooler |
| Dimensions | 482.6 (W) x 450 (D) x 177 (H) mm |
| TPM | (1) TPM Header |
