WMC-302M – Wallmount Chassis

WMC-302M – Wallmount Chassis

Mini-ITX Chassis with One 5.25" and One 3.5” Drive bays, support 1U single power supply

  • Heavy-Duty steel Contruction, SECC 1.0t
  • Support Mini-ITX motherboard
  • Front door with replaceable filter
  • (1) 5.25″ external drive bay
    (1) 3.5″ Internal drive bay
  • (2) Front USB 2.0 ports
  • (1) Full-height expansion slot
  • (2) 60mm ball-bearing fans
  • Support 1U single power supply
WMC-302M

Description

WMC-302M – Wallmount Chassis

Board Support Mini-ITX motherboard
Expansion Slots (1) Full-height expansion slot
Drive Bays (1) 5.25″ external drive bay
(1) 3.5″ internal drive bay
Front Panel Power On/Off and Reset Switch
Power On/Off and HDD activity with LED indicators
(2) USB 2.0 ports
Power Supply 1U Single power supply
Cooling (2) 60mm ball-bearing fan
Dimensions 235 (W) x 320 (D) x 132 (H) mm; 9.25 (W) x 12.6 (D) x 5.19 (H) inches
Net Weight 3.2kg / 7.1lbs

WMC-302M-BLK Mini chassis for Mini-ITX MB with (1) 5.25” and (1) 3.5” Drive bays
WMC-302M-300W Mini chassis for Mini-ITX MB with (1) 5.25” and (1) 3.5” Drive bays with 300W PSU
WMC-302M-460W Mini chassis for Mini-ITX MB with (1) 5.25” and (1) 3.5” Drive bays with 460W PSU
